SURAN
Laser-welded diamond core drills for precision hole cutting in hard materials like concrete and masonry.
| Art. No. | Outer Diameter | Effective depth | Segment Height | Connection |
| DCBB 028 | 28 (1.1") | 270 400 | 7/8/9/10 | 1/2"BSP-11/1 1/4"UNC-7 |
| DCBB 032 | 32 (1.25") | 270 400 | 7/8/9/10 | 1/2"BSP-11/1 1/4"UNC-7 |
| DCBB 037 | 37 (1.45") | 270 400 | 7/8/9/10 | 1/2"BSP-11/1 1/4"UNC-7 |
| DCBB 042 | 42 (1.65") | 270 400 | 7/8/9/10 | 1/2"BSP-11/1 1/4"UNC-7 |
| DCBB 047 | 47 (1.85") | 270 400 | 7/8/9/10 | 1/2"BSP-11/1 1/4"UNC-7 |
| DCBB 052 | 52 (2.04") | 270 400 | 7/8/9/10 | 1/2"BSP-11/1 1/4"UNC-7 |
| DCBB 057 | 57 (2.2") | 270 400 | 7/8/9/10 | 1/2"BSP-11/1 1/4"UNC-7 |
| DCBB 062 | 62 (2.44") | 270 400 | 7/8/9/10 | 1/2"BSP-11/1 1/4"UNC-7 |
| DCBB 067 | 67 (2.6") | 270 400 | 7/8/9/10 | 1/2"BSP-11/1 1/4"UNC-7 |
| DCBB 072 | 72 (2.83") | 270 400 | 7/8/9/10 | 1/2"BSP-11/1 1/4"UNC-7 |
| DCBB 077 | 77 (3") | 270 400 | 7/8/9/10 | 1/2"BSP-11/1 1/4"UNC-7 |
| DCBB 082 | 82 (3.22") | 270 400 | 7/8/9/10 | 1/2"BSP-11/1 1/4"UNC-7 |
| DCBB 087 | 87 (3.42") | 270 400 | 7/8/9/10 | 1/2"BSP-11/1 1/4"UNC-7 |
| DCBB 092 | 92 (3.62") | 270 400 | 7/8/9/10 | 1/2"BSP-11/1 1/4"UNC-7 |
| DCBB 102 | 102 (4") | 270 400 | 7/8/9/10 | 1/2"BSP-11/1 1/4"UNC-7 |
| DCBB 107 | 107 (4.2") | 270 400 | 7/8/9/10 | 1/2"BSP-11/1 1/4"UNC-7 |
| DCBB 112 | 112 (4.4") | 270 400 | 7/8/9/10 | 1/2"BSP-11/1 1/4"UNC-7 |
| DCBB 122 | 122 (4.8") | 270 400 | 7/8/9/10 | 1/2"BSP-11/1 1/4"UNC-7 |
| DCBB 127 | 127 (5") | 270 400 | 7/8/9/10 | 1/2"BSP-11/1 1/4"UNC-7 |
| DCBB 132 | 132 (5.2") | 270 400 | 7/8/9/10 | 1/2"BSP-11/1 1/4"UNC-7 |
| DCBB 142 | 142 (5.6") | 270 400 | 7/8/9/10 | 1/2"BSP-11/1 1/4"UNC-7 |
| DCBB 152 | 152 (6") | 270 400 | 7/8/9/10 | 1/2"BSP-11/1 1/4"UNC-7 |
| DCBB 162 | 162 (6.37") | 270 400 | 7/8/9/10 | 1/2"BSP-11/1 1/4"UNC-7 |
| DCBB 172 | 172 (6.77") | 270 400 | 7/8/9/10 | 1/2"BSP-11/1 1/4"UNC-7 |
| DCBB 182 | 182 (7") | 270 400 | 7/8/9/10 | 1/2"BSP-11/1 1/4"UNC-7 |
| DCBB 192 | 192 (7.5") | 270 400 | 7/8/9/10 | 1/2"BSP-11/1 1/4"UNC-7 |
| DCBB 200 | 200 (8") | 270 400 | 7/8/9/10 | 1/2"BSP-11/1 1/4"UNC-7 |
| DCBB 212 | 212 (8.3") | 270 400 | 7/8/9/10 | 1/2"BSP-11/1 1/4"UNC-7 |
| DCBB 225 | 225 (8.8") | 270 400 | 7/8/9/10 | 1/2"BSP-11/1 1/4"UNC-7 |
| DCBB 250 | 250 (10") | 270 400 | 7/8/9/10 | 1/2"BSP-11/1 1/4"UNC-7 |
| DCBB 257 | 257 (10") | 270 400 | 7/8/9/10 | 1/2"BSP-11/1 1/4"UNC-7 |
| DCBB 300 | 300 (12") | 270 400 | 7/8/9/10 | 1/2"BSP-11/1 1/4"UNC-7 |
| DCBB 350 | 350 (14") | 270 400 | 7/8/9/10 | 1/2"BSP-11/1 1/4"UNC-7 |
| DCBB 400 | 400 (16") | 270 400 | 7/8/9/10 | 1/2"BSP-11/1 1/4"UNC-7 |
| DCBB 450 | 450 (18") | 270 400 | 7/8/9/10 | 1/2"BSP-11/1 1/4"UNC-7 |
| DCBB 500 | 500 (20") | 270 400 | 7/8/9/10 | 1/2"BSP-11/1 1/4"UNC-7 |
| DCBB 550 | 550 (22") | 270 400 | 7/8/9/10 | 1/2"BSP-11/1 1/4"UNC-7 |
| DCBB 600 | 600 (24") | 270 400 | 7/8/9/10 | 1/2"BSP-11/1 1/4"UNC-7 |
