Model:
COLD PRESSED GENERAL PURPOSE BLADE
Brand:
SURAN
Code:
0101

Product Description

Sintered Segmented Diamond Blade

Sintered Dry Cutting Diamond Blade

Advantages:high speed of cutting,long life-span of using,smooth cutting edge,suitable for cutting tiles,ceramics,marble,etc.

Item No.	Outer Diameter		Hole Diameter mm	Segment Dimension	Segment Number
Item No.	inch	mm	Hole Diameter mm	Segment Dimension	Segment Number
0101105	4"	105	16/20/22.23	1.8x7.0x35	8
0101110	4.3"	110	16/20/22.23	1.9x7.0x32.3	8
0101115	4.5"	115	20/22.23	1.9x7.0x38.3	8
0101125	5"	125	20/22.23	2.0x7.0x37.5	9
0101150	6"	150	20/22.23	2.0x7.0x33.5	12
0101180	7"	180	22.23/25.4/30	2.2x7.0x35	14
0101200	8"	200	22.23/25.4/30	2.4x7.0x34.4	14
0101230	9"	230	22.23/25.4/30/50	2.4x7.2x34.4	18
0101250	10"	250	22.23/25.4/30/50	2.8x7.5x37	18
0101300	12"	300	22.23/25.4/30/50	3.2x7.5x35	22
0101350	14"	350	22.23/25.4/30/50	3.2x7.5x40	24
0101400	16"	400	22.23/25.4/30/50	3.4x7.5x40	28
